UP 10×21 Porro Prism Binoculars Black

OVERVIEW

The compact and lightweight 10×21 UP Binocular combines aspherical optical elements and BAK4 Porro prisms to deliver edge-to-edge image sharpness with a 50° angle of view. The optical elements are also fully multicoated to provide a high transmission of light. With an 10x magnification and 21mm objectives, you obtain a higher than average magnification and a compact form factor. You can easily spot your targets with a wide 5° angular field of view and quickly bring them into focus with a center focus wheel. In addition to observing distant scenes, birds and game, the minimum focus of 9.2′ allows you to study in detail close objects like animal footprints, marks or landscape features. The binocular also features a 2.1mm exit pupil, a 9.5mm eye relief, an interpupillary and a diopter adjustments.

The binocular is very compact, lightweight, and features a single piece frame that houses objectives, which allows for a synchronized interpupillary adjustment. To accommodate eye glasses wearers, the binocular offers sliding rubber eyecups. Also included are a carrying case, a neck strap, and eyepiece covers.

Optical Performance

Construction Details

SPECIFICATIONS

Prism TypePorro
Magnification10x
Objective Lens Diameter21 mm
Angle of View5° (actual)
Field-of-View261′ @ 1000 yd / 86.65 m @ 1000 m
Minimum Focus Distance9.24′ / 2.82 m
Exit Pupil Diameter2.1 mm
Eye Relief9.5 mm
Focus TypeCentre
Dimensions4.3 x 3.14 x 1.9″ / 10.92 x 7.98 x 4.83 cm
Weight7.4 oz / 210 g
